Volta 10.24kWh Battery

The Volta 10.24kWh Battery (STAGE 3) is a lithium iron phosphate (LiFePO4) battery for storing the day's solar and carrying a house through the evening and the night. Enough for a normal household evening with the fridge, the lights and the usual plugs, and enough left to see the night out.

Key Features & Specifications:

• 8.19 kWh Usable - Rated at 10.24 kWh, of which 8.19 kWh is usable - a depth of discharge of 80%. Usable capacity is the figure to size against - it is what you actually get out of it between sunset and sunrise.
• 150 A Charge - Charges and discharges at up to 150 A, peaking at 150 A for a motor starting.
• 51.2 V Nominal - Operates between 44.8 and 56.8 V, which is the window the inverter has to match - a battery and an inverter that do not overlap here will not work together whatever else they have in common.
• 6,000 Cycles - One cycle is one full charge and discharge. At a cycle a day that is roughly 16 years of daily use before the rated capacity falls away.
• Talks to the Inverter - CAN, RS485, USB. The battery tells the inverter its state of charge and its limits, so charging stops where it should instead of at a guessed voltage.
• Up to 16 in Parallel - Start with one and add more as the load grows, up to 16 together, without replacing what is already installed.
• The Unit Itself - 200 Ah, 89 kg. Worth checking against where it is going to live and what is going to carry it.

Part number STAGE 3. Ask us for the full datasheet, the warranty terms and a certificate of compliance before you commit to a system.
